400mW Zener Diode Pak 2V to 47V 340 Pcs 34 Values

SKU: EP44

Brand: Generic

Type: Through Hole

Series: 400 mW Zener Diode

Power Dissipation: 400mW

Voltage Range: 2.0 V to 47 V

Tolerance: ±5 %

Reverse Voltage: Zener breakdown voltage specific to each model

Package Type: DO-35

Test Current: 20 mA

Maximum Zener Impedance: 100 Ω (varies by voltage rating)

₹545.00

Add to wishlist

Description

400mW Zener diodes are designed for efficient voltage regulation and protection in electronic circuits. With a power dissipation rating of 400mW, they are suitable for a wide range of low to medium power applications. These diodes feature a stable reverse breakdown voltage, making them ideal for maintaining voltage levels within a desired range. They come in a variety of voltage ratings, offering flexibility for different design requirements. The diodes are housed in a standard DO-35 package, known for its compact size and reliable performance.

This assortment pack includes 340 high-quality 400mW Zener diodes in 34 different voltage ratings, ranging from 2.0V to 47V. Each voltage type comes in a pack of 10 pieces, ensuring you have ample quantity for various applications. These Zener diodes are widely used for voltage regulation, protection, and circuit stabilization in electronic projects.

Symbol:

Zener Diode Structure:

Zener Diode Part Code:

Zener Diode V-I Characteristics:



The VI characteristic of the Zener diode is shown in the figure below. When the diode is connected in forward bias, this diode work like a normal diode. But When a reverse voltage is applied across the diode. initially a small reverse saturation current Io flows across the diode. As the reverse voltage is increased, at a certain value of reverse voltage, the junction will be

Package Includes

340 400mW Zener Diode 34 Types

  • 0 V - 10 Pcs
  • 2 V - 10 Pcs
  • 4 V - 10 Pcs
  • 7 V - 10 Pcs
  • 0 V - 10 Pcs
  • 3 V - 10 Pcs
  • 6 V - 10 Pcs
  • 9 V - 10 Pcs
  • 3 V - 10 Pcs
  • 7 V - 10 Pcs
  • 1 V - 10 Pcs
  • 6 V - 10 Pcs
  • 2 V - 10 Pcs
  • 8 V - 10 Pcs
  • 5 V - 10 Pcs
  • 2 V - 10 Pcs
  • 1 V - 10 Pcs
  • 10 V - 10 Pcs
  • 11 V - 10 Pcs
  • 12 V - 10 Pcs
  • 13 V - 10 Pcs
  • 15 V - 10 Pcs
  • 16 V - 10 Pcs
  • 18 V - 10 Pcs
  • 20 V - 10 Pcs
  • 22 V - 10 Pcs
  • 24 V - 10 Pcs
  • 27 V - 10 Pcs
  • 30 V - 10 Pcs
  • 33 V - 10 Pcs
  • 36V - 10 Pcs
  • 39 V - 10 Pcs
  • 43 V - 10 Pcs
  • 47 V - 10 Pcs

Features:

  • Stable and reliable voltage regulation
  • Versatile for various circuit applications
  • Cost-effective
  • Ideal for prototyping and learning
  • High-quality, long-lasting components

Applications:

  • Voltage Regulation - Maintains a stable voltage level in circuits by acting as a reference
  • Overvoltage Protection - Prevents excessive voltage from damaging sensitive components
  • Signal Clipping - Limits signal amplitude to prevent distortion in audio and communication circuits
  • Waveform Shaping - Helps in creating precise signal shapes for circuit design and testing
  • Reference Voltage Source - Provides a fixed voltage for ADCs, sensors, and precision circuits
  • Surge Suppression - Protects circuits from voltage spikes in power lines
  • Power Supply Protection - Ensures safe operation by stabilizing output voltages
  • DIY and Prototyping - Used in hobby projects, experiments, and circuit testing
1. How should I connect a Zener diode in a circuit?

For voltage regulation, connect the Zener diode in reverse bias (cathode to positive, anode to negative) with a current-limiting resistor.

2. Do these Zener diodes work with AC or DC circuits?

They are primarily designed for DC circuits where voltage regulation is required.

3. Can I use these Zener diodes for voltage reference in microcontrollers?

Yes, they are commonly used as voltage reference sources in ADC circuits and microcontroller applications.

4. Can I use multiple Zener diodes in series or parallel?

Yes, connecting in series increases the total Zener voltage, while parallel connections share the current but should be avoided due to uneven current distribution.

5. Do Zener diodes conduct in forward bias?

Yes, like regular diodes, they conduct in forward bias but are mainly used in reverse bias for voltage regulation.

6. What is the difference between a Zener diode and a Schottky diode?

A Zener diode regulates voltage in reverse bias, while a Schottky diode has a low forward voltage drop and is used for fast switching.

7. Can I use a Zener diode as a voltage booster?

No, Zener diodes only regulate or clamp voltage; they do not increase voltage like boost converters.

8. What is the leakage current of a Zener diode?

In reverse bias, there is a small leakage current (nanoamps to microamps) before reaching breakdown voltage.



9. What is the leakage current of a Zener diode?

In reverse bias, there is a small leakage current (nanoamps to microamps) before reaching breakdown voltage.

10. Can I purchase specific types individually rather than in a pack?

This product is sold as a complete pack, but individual types may be available separately upon request.
