Ceramic Disc Capacitor 50V Pak 10pF to 0.22µF 240 Pcs 18 Values

SKU: EP7

Technical Specification:

Type: Through Hole
Model: Ceramic Disc Capacitor
Capacitance Range: 10 pF – 0.22 µF
Lead Spacing: 2.5 mm – 5 mm
Voltage Rating: 50 V
Lead Type: Radial
Tolerance: ±10 %
Operating Temperature: -25 °C to +85 °C
Pak Weight: 70 gm
Pak Dimensions: 127 x 80 x 24 mm

₹230.00

Add to wishlist

Description

Ceramic Disc Capacitor 50V Pak 10pF to 0.22µF 240 Pcs 18 Values

Ceramic disc capacitors are passive electronic components that store and release electrical energy using a ceramic dielectric. They are non-polarized and typically come in a disc shape with two metal leads for easy mounting. These capacitors are known for their high stability, low leakage, and fast response time. They are available in various capacitance values and voltage ratings, making them suitable for different circuit requirements. Constructed with a ceramic material as the insulating layer, they offer reliability and durability in electronic circuits.

Capacitor Symbol:

Disc Cap Part Code:

Disc Cap Structure:

Explore a wide range of capacitors for electronic projects, repairs, prototyping and circuit applications.

Package Includes

240 Ceramic Disc Capacitors 50V 18 Types

10 pF – 10 Pcs
22 pF – 20 Pcs
33 pF – 20 Pcs
47 pF – 10 Pcs
100 pF – 20 Pcs
220 pF – 10 Pcs
330 pF – 10 Pcs
470 pF – 10 Pcs
1 KpF – 20 Pcs
2.2 KpF – 10 Pcs
3.3 KpF – 10 Pcs
4.7 KpF – 10 Pcs
10 KpF – 20 Pcs
22 KpF – 10 Pcs
33 KpF – 10 Pcs
47 KpF – 10 Pcs
100 KpF – 20 Pcs
220 KpF – 10 Pcs

Additional Information
FAQs

Features:

Wide Range of Capacitance Values
Stable & Reliable
High Insulation Resistance
Compact Size
Long Lifespan
Easy to Solder

Applications:

Electronic Prototyping – Ideal for DIY projects and circuit designs
Signal Filtering – Removes unwanted noise from electronic signals
Decoupling & Bypassing – Used in power supply circuits
Oscillator Circuits – Helps stabilize frequency in oscillators
Timing Circuits – Works in RC timing and delay circuits
Consumer Electronics – Used in radios, TVs, and amplifiers
Microcontroller & Embedded Systems – Essential for stabilizing signals in Arduino and Raspberry Pi projects

1. Can they replace electrolytic capacitors?

No, electrolytic capacitors have higher capacitance values and are polarized.

2. Do they have self-healing properties?

No, unlike film capacitors, they do not self-heal after breakdown.

3. Do ceramic disc capacitors have polarity?

No, they can be connected in any direction.

4. What happens if I exceed the voltage rating of a ceramic capacitor?

It may break down, short-circuit, or even crack.

5. Are they suitable for high-frequency applications?

Yes, especially low-capacitance values.

6. Can I parallel ceramic capacitors to increase capacitance?

Yes, connecting capacitors in parallel adds their capacitance values.

7. How do I test if a capacitor from the pack is working?

Use a multimeter with capacitance measurement or an LCR meter to check the value.

8. Are these ceramic disc capacitors suitable for beginner electronics projects?

Yes, they are easy to use and great for learning circuit design and prototyping.

9. How do I identify the capacitance of a capacitor from the pack?

Look for the three-digit code on the capacitor or specification table of the product if needed.

10. Can I purchase specific types individually rather than in a pack?

This product is sold as a complete pack, but individual types may be available separately upon bulk request.
