5mm Diffused LED Pak 600 Pcs 6 Colors

SKU: EP33

Technical Specification:

Type: Through Hole
Product Type: 5mm Diffused LED Pak
Model: Diffused LED
Size: 5 mm
Colors: Red, Green, Blue, Yellow, White, Orange
Fwd. Voltage: 1.8 V – 3.4 V
Fwd. Current: 20 mA
Viewing Angle: 25° – 60°
Luminous Intensity: 800 – 3000 mcd
Wavelength:
- Red, Green, Blue, Yellow, Orange: 515 nm – 630 nm
- White: 6000 – 7000 K
Pak Weight: 230 gm
Pak Dimensions: 150 x 100 x 35 mm

₹645.00

Add to wishlist

Description

5mm Diffused LED Pak 600 Pcs 6 Colors

The 5mm Diffused LED Pak is a versatile assortment for electronics projects, circuit testing, repairs and creative lighting applications. It includes 600 LEDs in six different colors, giving users a convenient selection for building indicators, displays, prototypes and decorative circuits.

Each LED features a 5mm diffused lens that spreads light evenly and provides a softer glow than clear-lens LEDs. The 5mm Diffused LED Pak is suitable for breadboards, control panels, educational kits, model making, DIY electronics, status indicators and custom lighting projects.

LED Symbol:

LED Structure:

Explore a wide range of LEDs for indicators, displays, lighting, circuit prototyping and creative electronic projects.

Package Includes

600 Diffused 5mm LED 6 Colors

5mm Red - 100 Pcs
5mm Green - 100 Pcs
5mm Blue - 100 Pcs
5mm Yellow - 100 Pcs
5mm White - 100 Pcs
5mm Orange - 100 Pcs

Additional Information
FAQs

Features:

Energy-efficient, low power consumption
Long lifespan of 50,000+ hours
Diffused lens for uniform light distribution
Wide viewing angle (30° - 60°)
Suitable for Arduino, Raspberry Pi, and circuit projects
High brightness with stable illumination
Compact 5mm size, easy to fit in breadboards and PCBs
Operates at low voltage (1.8V - 3.2V) with minimal heat
Easy to use with a standard through-hole design

Applications:

Electronic Prototyping - Used in breadboards and circuit testing
Arduino & Raspberry Pi Projects - Ideal for indicator lights and displays
DIY Electronics & Hobby Projects - Great for custom lighting and creative builds
Indicator Lights - Used in home appliances, power status indicators, and control panels
Automotive Applications - Dashboard indicators, signal lights, and interior lighting
Decorative Lighting - Used in signage, models, and ambient lighting setups
Toys & Gadgets - Adds visual effects and interactive lighting to toys
Educational Kits - Helps students learn electronics and circuit design
Wearable Electronics - Integrated into costumes, accessories, and smart clothing
Remote Controls & IR Applications - Some variants used for infrared signaling

1. What is the difference between diffused and clear LEDs?

Diffused LEDs have a frosted lens that spreads light evenly, while clear LEDs produce a focused, bright spot.

2. Are these LEDs pre-wired?

No, these are through-hole LEDs and need to be soldered onto a circuit board.

3. Do these LEDs require resistors?

Yes, resistors are recommended to limit current and avoid damaging the LEDs, depending on your power supply.

4. What is the size of the LED's lead?

The lead size is standard for 5mm LEDs, usually around 0.5mm in diameter.

5. Are these LEDs polarized?

Yes, LEDs are polarized components. The long lead is the anode (+) and the short lead is the cathode (-).

6. Can these LEDs be dimmed?

Yes, these LEDs can be dimmed by adjusting the voltage or using a PWM controller.

7. Can I solder these LEDs to a PCB?

Yes, these through-hole LEDs can easily be soldered onto a printed circuit board (PCB) for permanent installations.

8. Can these LEDs be used in a series circuit?

Yes, these LEDs can be connected in series with appropriate resistors.

9. Are the LEDs pre-assembled into any form?

No, the LEDs are not pre-assembled and need to be soldered individually.

10. Can I purchase specific types individually rather than in a pack?

This product is sold as a complete pack, but individual types may be available separately upon bulk request.
